Tech Specs
Product features and specifications are subject to change without prior notice.
-
Technology
Printing Method
PrecisionCore™ Print Head
Nozzle Configuration
800 Nozzles Black, 800 Nozzles per Color
Minimum Droplet Size
3.8 pl
Printing Resolution
4,800 x 1,200 DPI
Category
Home Office, Office Desktop
All-in-One Functions
Print, Scan, Copy, Fax
-
Print
Printing Speed ISO/IEC 24734
25 pages/min Monochrome, 25 pages/min Colour
Printing Speed
32 pages/min Monochrome (plain paper 75 g/m²), 32 pages/min Colour (plain paper 75 g/m²)
Duplex Printing Speed ISO/IEC 24734
21 A4 Pages/min Monochrome, 21 A4 Pages/min Colour
First Page Out
Monochrome 5.5 Seconds, Colour 6 Seconds
Colours
Black, Cyan, Yellow, Magenta
-
Scan
Double-sided scanning
Yes
Single-sided scan speed (A4 black)
27.5 ipm with ADF scan 5 sec. with flatbed scan
Doubled-sided scan speed (A4 black)
11 ipm with ADF scan
Single-sided scan speed (A4 colour)
9 ipm with ADF scan 10 sec. with flatbed scan
Doubled-sided scan speed (A4 colour)
6 ipm with ADF scan
Optical Resolution
1,200 DPI x 2,400 DPI (Horizontal x Vertical)
Optical Resolution (ADF)
1,200 DPI x 2,400 DPI (Horizontal x Vertical)
Output formats
BMP, JPEG, TIFF, multi-TIFF, PDF, PNG
Scanner type
Contact image sensor (CIS)
-
Fax
Type of fax
Walk-up black and white and colour fax capability
Fax Transmission Speed
Up to 33.6kbps / Approx. 3 sec/page
Error correction mode
CCITU/ITU Group3 fax with Error Correction Mode
Fax speed dials (max)
200 names and numbers
Page memory
Up to 550 pages/ 6MB (ITU-T No. 1 chart)
Fax Functions
PC Fax, Fax to E-mail, Memory Reception, Auto Redial, Address Book, Broadcast Fax, Fax Preview, Polling Reception
-
Paper / Media Handling
Paper Formats
A4 (21.0x29.7 cm), A5 (14.8x21.0 cm), A6 (10.5x14.8 cm), B6 (12.5x17.6 cm), B5 (17.6x25.7 cm), No. 10 (Envelope), DL (Envelope), C6 (Envelope), C4 (Envelope), Letter, Legal
Duplex
Yes (A4, plain paper)
Automatic Document Feed
50 pages
Output Tray Capacity
125 Sheets
multifunction
550 Sheets Standard
Rear paper path (special media)
Yes
Compatible Paper Weight
64 g/m² - 255 g/m²
Media Handling
ADF 2-sided copy (A4, plain paper), ADF 2-sided fax (A4, plain paper), ADF 2-sided scan (A4, plain paper), Automatic duplex (A4, plain paper)
-
General
Energy Use
19 Watt (standalone copying, ISO/IEC 24712 pattern), 0.8 Watt (sleep mode), 9.1 Watt (Ready), 0.2 Watt (Power off), TEC 0.14 kWh/week
Supply Voltage
AC 220 V - 240 V, 50 Hz - 60 Hz
Product dimensions
425 x 500 x 350 mm (Width x Depth x Height)
Compatible Operating Systems
Mac OS X 10.6.8 or later, Windows 10 (32/64 bit), Windows 7 (32/64 bit), Windows 8 (32/64 bit), Windows 8.1 (32/64 bit), Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Vista (32/64 bit), Windows XP Professional x64 Edition SP2 or later, Windows XP SP3 or later (32-bit), Windows Server 2003 R2, spectextoptionoperatingsystemswin2003ii2, XP Professional x64 Edition
Interfaces
USB, Ethernet, Wireless LAN IEEE 802.11a/b/g/n/ac, Wi-Fi Direct
WLAN Security
WEP 64 Bit, WEP 128 Bit, WPA PSK (TKIP)
Mobile and Cloud printing services
Epson Connect (iPrint, Email Print, Remote Print Driver, Scan-to-Cloud), Apple AirPrint
What’s in the box
1 set of ink (1x 127ml BK, 3x 70ml CMY), Main unit, Power cable, Quick Start Guide, User guide
-
Other Features
Panel
Type: Color, Touchscreen, Diagonal: 10.9 cm
-
Included Bottle Yield
|
